New · Part number: ARElD-BPV-xx
Vertical Binary Floor Display 4.5x6.5 cm
What you need to know about this product
- Thin vertical dot-matrix display board that can be installed in COP (Cabin Operation Panel) push-button stations but is primarily used in LOP (Landing Operation Panel) push-button stations. The display can show elevator direction, floor messages, the current floor of the elevator, and special message functions.
- The binary code supports a maximum of 31 floors; customization is required when there are more floors or special floors with alphabet letters.
- Features
- Display Type: Binary (Parallel).
- Nominal Voltage: 24 VDC.
- Shipping to be quotedYou only pay for the products; an advisor will quote shipping after your purchase.
Online checkout is paused for now: add the parts to your quote and an advisor will reply with the final price, shipping and how to pay.
- Sold by Elevadores Alamex · over 20 years in the elevator industry · ISO 9001 certified.
What you need to know about this product
- Thin vertical dot-matrix display board that can be installed in COP (Cabin Operation Panel) push-button stations but is primarily used in LOP (Landing Operation Panel) push-button stations. The display can show elevator direction, floor messages, the current floor of the elevator, and special message functions.
- The binary code supports a maximum of 31 floors; customization is required when there are more floors or special floors with alphabet letters.
- Features
- Display Type: Binary (Parallel).
- Nominal Voltage: 24 VDC.
Specifications
| Part number | ARElD-BPV-xx |
|---|
Data from the Alamex catalog. Reference images; specifications may vary by model.
Description
Thin vertical dot-matrix display board that can be installed in COP (Cabin Operation Panel) push-button stations but is primarily used in LOP (Landing Operation Panel) push-button stations. The display can show elevator direction, floor messages, the current floor of the elevator, and special message functions. The binary code supports a maximum of 31 floors; customization is required when there are more floors or special floors with alphabet letters. Features Display Type: Binary (Parallel). Nominal Voltage: 24 VDC. Board Dimensions: 83 mm length x 58 mm width. Display Color: Red or Orange. Position: Vertical. Location: Floor. Does not include metal enclosure.
